Piegāde 3 dienas
MULTIPLEXER ~ U-PROX modulis vadu apsardzes iekārtu pieslēgšanai
178,11€
bez PVN: 147,20€
- Noliktavā: 5
- Ražotājs: U-PROX
- Kods: 012670
Informācija.
| Inputs | 8 (Z1 ... Z8) |
|---|---|
| Output | 1 relay (NO C) |
| LED | 3V |
| Power output | 2 outputs AUX and SWA (controlled output), with self-restoring fuses, 200 mA 12V |
| Power | 10,8 ... 13,8V |
| Battery backup | two 2500 mAh batteries, up to 10 hours (with 8 wired detectors, 15 mA each) |
| Radio frequency | ISM wireless interface with multiple channels: ITU Region 1: 868.0...868.6 MHz (EU, UA), 869.0...869.4 (MA), 100 kHz bandwidth, 20 mW max, distance - up to 4800m (in open space); ITU region 3 (AU): 916.5...917 MHz, 100 kHz bandwidth, 20 mW max, distance to devices - up to 4800 m (in open space). |
| Communication | Two-way, encrypted, with sabotage (jamming) detection. The encryption key is 256 bits |
| Operating temperature range | -10°C ... +45°C |
| Permissible humidity | up to 75% |
| Environmental class | II (according to EN 50131-1) |
| Security grade | 2 |
| Dimensions | 167 х 120 х 38 mm |
| Case colour | білий |
| Weight | 0.64 kg |
| Complete set | 1. U-Prox Multiplexer; 2. Two 18650 batteries (pre-installed); 3. Short user manual |
| Īpašības | |
| Materiāls | Plastikāts |
| Iekārtu kategorija | Integrācijas risinājumi |
| Krāsa | Balta |
